5000A/8000A Double Side Automatic Spot Welding Machine For Lithium-Ion Battery

Brand Name:	XWELL
Model Number:	MD-ADW
MOQ:	1pcs
Price:	USD 11000 - 15000 / pcs
Packaging Details:	Wooden box
Payment Terms:	T/T,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Compliance:

CE Certified

Payment:

L/C D/A D/P T/T Western Union

Operate System:

Embedded System

User Interface:

Touch Screen

Power Source:

5000A / 8000A / 10000A Optional

Efficiency:

3800pcs/h

Equipment Stroke:

500*350 (mm) About 760 18650 Cells

Maximum Load Capacity:

200-400pcs(standard 18650 Lithium Battery)

Operating System:

Embedded System + Man - Machine Screen

Transmission Mode:

Step + Belt + Imported Precision Linear Guide Rail (optional Servo + Screw)

Brand:

XWELL

Supply Ability:

100pcs per month

Highlight:

5000A lithium battery spot welder

8000A automatic spot welding machine

double side lithium battery welder

Product Description

5000A/8000A Double Side Automatic Spot Welding Machine For Lithium-Ion Battery

Product Description

This double-sided spot welding machine is equipped with a 10000A transistor welding power supply, which has the function of detecting the contact resistance between the weldment or the weldment and the welding needle. It can be well utilized to detect the welding resistance before spot welding, avoiding damage to the weldment and the welding needle during welding, and achieving high-precision and high reliability welding.

Advantages of transistor welding power :

The welding frequency is the highest in the industry (175KHz), and the pulse power is the strongest in the industry.
The welding current rises quickly, which can realize high-quality welding on the workpiece in a very short time.
Constant current, constant voltage, constant current and constant voltage three control modes.
With weldment resistance detection function, high reliability and high precision welding can be realized.
It has the function of slow rise and fall of current and voltage.
Fully closed-loop control can precisely control welding current and welding voltage.

Product Specification

SPECIFICATIONS FOR MD-ASW AND MD-ADW
	MD-ASW	MD-ADW
Welding Head Number	1	2
Travel	X: 400mm; Y: 400mm	Y: 500mm; Z: 350mm
Welding Spped	0.5s/spot, 2000-2500pcs/h	0.5s/spot, 3500-4000pcs/h
Welder Power Suppler	5000A Inverter Spot Welder
Max Motor Speed	1000mm/s
Max Battery Number	450 pcs (18650)
Operate System	Embedded system
User Interface	Touch screen
Drive Mode	Step motor and precision guide rail
Power Supply	220V/50Hz(machine); 3 phase, 380V/50Hz(Welder)
Air Pressure	0.3-0.6 MPa
Machine Size	900L900W1750Hmm	1100L900W1930Hmm
Machine Weight	200kg	350kg

Product Application

MD-ADW can be used in electric tool battery, torsion car battery, Energy Storage Battery Pack, Scooter Electric Vehicle Battery, etc. Compared with manual spot welding, the efficiency and accuracy of welding have been greatly improved.

Product Operation

1. Setting the parameters of welding on the touch screen. (The same product only need to be set once)
2. Put the fixture with the battery pack on the quick clamping position.
3. Press the start button, the machine automatically complete all welding actions.
4. The welder sound to prompt operator replacement of new fixture (battery pack).

Double side spot welder details

5000A/8000A Double Side Automatic Spot Welding Machine For Lithium-Ion Battery

Cylindrical battery pack welding samples

5000A/8000A Double Side Automatic Spot Welding Machine For Lithium-Ion Battery
