Automatic Double Sides Welding Head Battery Pack Spot Welding Machine

Brand Name:	XWELL
Model Number:	MD-ADW
MOQ:	1pcs
Price:	USD 11000 - 15000 / pcs
Packaging Details:	Wooden box
Payment Terms:	T/T,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Compliance:

CE Certified

Payment:

L/C D/A D/P T/T Western Union

Operate System:

Embedded System

User Interface:

Touch Screen

Power Source:

5000A / 8000A / 10000A Optional

Efficiency:

3800pcs/h

Equipment Stroke:

500*350 (mm) About 760 18650 Cells

Maximum Load Capacity:

200-400pcs(standard 18650 Lithium Battery)

Operating System:

Embedded System + Man - Machine Screen

Transmission Mode:

Step + Belt + Imported Precision Linear Guide Rail (optional Servo + Screw)

Supply Ability:

100pcs per month

Highlight:

automatic double sides welding machine

battery pack spot welding machine

lithium battery spot welding head

Product Description

Automatic Double Sides Welding Head Battery Pack Spot Welding Machine

Advantages

1) Induce load voltage, control voltage by feedback, and realize high quality welding.

2) Preheat, Main Heat's power mode, preheating before welding, to ensure stable welding quality.

3) Keep the continuity of energy density, shorten the welding time, and reduce the deformation and color of base metal. (Welding time controlled in microseconds, continuous output mode)

4) Easy to change from low current to high current, suitable for precision welding.

5) The upper and lower limits of current can be set to simply judge whether the welding quality is good or not, which is suitable for welding automation platform.

6) The welding current rises with the time of electrification to ensure the welding effect.

Key Features

CNC-controlled welding process
High positioning accuracy
Multiple welding parameter storage
Flexible fixture compatibility
Real-time welding quality monitoring
Low maintenance requirements

Operation:

1.Setting the parameters of welding on the touch screen. (The same product only need to be set once)

2.Put the fixture with the battery pack on the quick clamping position.

3.Press the start button, the machine automatically complete all welding actions.

4.The welder sound to prompt operator replacement of new fixture (battery pack).

Product Specification

SPECIFICATIONS FOR MD-ASW AND MD-ADW
	MD-ASW	MD-ADW
Welding Head Number	1	2
Travel	X: 400mm; Y: 400mm	Y: 500mm; Z: 350mm
Welding Spped	0.5s/spot, 2000-2500pcs/h	0.5s/spot, 3500-4000pcs/h
Welder Power Suppler	5000A Inverter Spot Welder
Max Motor Speed	1000mm/s
Max Battery Number	450 pcs (18650)
Operate System	Embedded system
User Interface	Touch screen
Drive Mode	Step motor and precision guide rail
Power Supply	220V/50Hz(machine); 3 phase, 380V/50Hz(Welder)
Air Pressure	0.3-0.6 MPa
Machine Size	900L900W1750Hmm	1100L900W1930Hmm
Machine Weight	200kg	350kg

Product Application

MD-ADW can be used in electric tool battery, torsion car battery, Energy Storage Battery Pack, Scooter Electric Vehicle Battery, etc. Compared with manual spot welding, the efficiency and accuracy of welding have been greatly improved.

Product Operation

1. Setting the parameters of welding on the touch screen. (The same product only need to be set once)
2. Put the fixture with the battery pack on the quick clamping position.
3. Press the start button, the machine automatically complete all welding actions.
4. The welder sound to prompt operator replacement of new fixture (battery pack).

Double side spot welder details

Automatic Double Sides Welding Head Battery Pack Spot Welding Machine

Cylindrical battery pack welding samples

Automatic Double Sides Welding Head Battery Pack Spot Welding Machine
