80V 5A Lithium Ion Battery Testing Equipment Discharge Tester
Product Details:
| Place of Origin: | China |
| Brand Name: | XWELL |
| Certification: | CE |
| Model Number: | BCDS80-05-10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | USD 2000/pcs |
| Packaging Details: | Wooden box |
| Delivery Time: | 15-20 days |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 100 pcs per month |
|
Detail Information |
|||
| Testing Range: | 7-80V | Accuracy: | ±1‰ |
|---|---|---|---|
| Charging Range: | 50-5000mA | Charging Accuracy: | ±(0.2% Of Reading +0.2% Of Range) |
| Discharge Range: | 50-10000mA | Constant Voltage Cut-off Current: | 50mA Minimum |
| Discharge Power: | ≤700W | Inspection Time: | Receive Real Time <2S |
| Highlight: | 80V heavy duty battery discharge tester,lithium ion battery testing equipment,5A lithium ion battery testing equipment |
||
Product Description
80V 5A Charge And 10A Discharge Battery Pack Aging Machine For Agv Lithium Battery Pack Lithium Battery Pack Aging
Product Description
Charging function: with constant current and constant voltage charging function
Discharge function: with constant current discharge function
Charge and discharge interface: fully meet the requirements of the same port and separate port for charging and discharging the battery pack, that is, 2 wires (P+ P-) and 3 wires (P+ P- C-), and can age the positive electrode to protect the negative plate from discharging Protection type power tool battery (CH+ P+ P-)
Check voltage protection: by charging and discharging the battery, can check whether the battery's charge protection and
discharge protection work.
Record the charge and discharge capacity: charge and discharge the battery, and record the charge and discharge capacity of the battery.
Safety protection: anti-reverse connection protection function; voltage upper and lower limit setting protection; safe discharge current protection.
Serial port connection mode: If the instrument is single or less than 3, it can be connected to the PC through the serial port, which can reduce the complexity of using the instrument.
Network connection mode: If there are more than 3 instruments, the network connection mode can be used. The PC computer only needs to provide a network port to control less than 60 instruments.
Control system: The software system of the aging instrument adopts the classic and mature C/S mode, and the communication mode is serial port and network.
Management software: Based on Windows operating system, using SQL database to store test data, which greatly facilitates the staff to query and export data online. According to the battery bar code, time, and device number, you can view the charge and discharge aging curve, and you can also export the curve.
Product Specification
|
Input power
|
AC 220V ±10% 50Hz
|
|
|
Voltage
|
Testing range
|
7-80V
|
|
Accuracy
|
±(0.2% of reading +0.2% of range)
|
|
|
Electric current
|
Charging range
|
50-5000mA
|
|
Charging accuracy
|
±(0.2% of reading +0.2% of range)
|
|
|
Discharge range
|
50-10000mA
|
|
|
Accuracy
|
±(0.2% of reading +0.2% of range)
|
|
|
Charge
|
Constant voltage cut-off current
|
50mA minimum
|
|
Capacity
|
Accuracy
|
±1‰
|
|
Power
|
Discharge power
|
≤700W
|
|
Time
|
Inspection time
|
Receive real time <2S
|
|
Timing range
|
0-999 hours/step
|
|
|
Data logging interval
|
≥5S
|
|
|
Number of cabinet channels
|
12 channels, 4 rows and 3 columns
|
|
|
Charge
|
Charging mode
|
Constant current and constant
voltage charging |
|
Cut-off condition
|
Voltage, current, relative time,
overcharge protection. |
|
|
Cycle
|
Cycle test range
|
1-999
|
|
Number of single cycle steps
|
100
|
|
|
Voltage and current
detection sampling |
Four-wire sampling
|
|
|
Database
|
Use SQL database to manage test data
|
|
|
Host computer
communication method |
Based on TCP/IP protocol, serial port
|
|
|
Data transmission mode
|
EXCEL,TXT,Chart
|
|
|
Communication interface
|
Network port
|
|
|
Case size
|
300*450*170mm
|
|
|
Cabinet size
|
960*600*1900mm
|
|
|
Battery space size
|
900*600*130mm
|
|
