270mm Battery Pack Production Machine , Lithium Ion Battery Making Machine
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | XWELL |
| Certification: | CE |
| Model Number: | XW |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | USD $5000 - $50000 / line |
| Packaging Details: | Wooden box |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1 line per month |
|
Detail Information |
|||
| Sticking Machine: | Aumatic Sticking Machine | Sorting Machine: | Automatic Sorting Machine |
|---|---|---|---|
| Checking Machine: | CCD Testing Machine | Spot Welder: | Automatic Spot Welding Machine |
| Test Machine: | Battery Performance Test System | Aging Machine: | Battery Aging Cabinet |
| Highlight: | 270mm Battery Pack Production Machine,18650 lithium ion battery making machine,lithium ion battery making machine |
||
Product Description
Automatic Line Assemby Battery Pack Production Machine
1. Scope of application of equipment: Mainly used in automotive battery modules, power batteries, energy storage batteries,power tools and other application battery pack fully automated production.
2. It only need 3 operators to finish the process from box cell to welding, for other process after welding, it will depends on detailed configuration to decide operator quantity.
3. Optional scanner function,
4. The 4-axis Yamaha robot is used to automatically put battery pack into bracket, stable and reliable.
5. Adopt HIKVISION series CCD to recognize battery anode and cathode, ensure there are no mistake for polarity.
6. Two sets of laser are used to clean the surface stains of positive and negative electrodes of cell to ensure the welding quality.
7. Storage of cell in hopper mode, up to 320 PCS per gear
8. Device Support Function: 18650 Fully Automatic Box Cell (10*10) Automatic Feeding- Automatic Padding- Automatic Scan Code- Automatic Sorting (5 OK, 1 NG) -Hopper Storage Core (up to 320 PCS)-Cell auto changing positive and negative poles-automatic scanning code-automatic laser cleaning 1-automatic spacing-Robotic feeding to holder -CCD detection-automatic laser cleaning 2-artificial cover bracket and upper die-A surface spot welding 1-A surface spot welding 2-die inversion-B surface spot welding 1-B surface spot welding 2-automatic removal of upper cover-manual Remove battery pack- Welding Performance Testing (Total Voltage Total Internal Resistance Series Voltage Series Internal Resistance) -Circulating Assembly Line
9. Maximum stroke of equipment: X-axis direction :430MM , Y-axis direction 270MM , If 20.5MM Spacing X-axis direction 21 pcs battery, Y-axis direction 13 pcs battery
10. Production efficiency: 5000-6000PCS/H
